Maytronics Bottom Lid Assy | 99919117

Description

MAYTRONICS | BOTTOM LID ASSY | 99919117

OPTIMUS 3295-328
MAYTRONICS 99919117

THIS IS THE COMPLETE BOTTOM LID ASSEMBLY USED ON THE DLX4 AND DLX5
THIS FITS ON THE BOTTOM OF THE CLEANER AND IS WHERE THE BAG ATTACHES

MATERIAL: BASICALLY WHITE PLASTIC WITH A FEW YELLOW PLASTIC ITEMS
ALONG WITH THE METAL BAG SUPPORTS, SPRINGS, AND SCREWS

SPECIAL NOTE: THIS VERY CLOSELY RESEMBLES THE 99919116 BOTTOM LID ASSEMBLY BUT THE BAG SUPPORT IS DIFFERENT.
THE 99919116 BAG SUPPORTS ARE STRAIGHT ACROSS THE TOP.
THE BAG SUPPORTS ON THIS UNIT HAVE A DOUBLE BEND ON THE TOP OF THE BAG SUPPORT

SHAPE: RECTANGULAR BASE WITH 2 METAL BAG SUPPORTS (BAG SUPPORTS HAVE 2 SLIGHT BENDS AT TOP)

LENGTH: 12-1/2″

WIDTH: 9-1/4

HEIGHT: 6-5/8″ (FROM BASE TO TOP OF BAG SUPPORT)

MARKINGS:
THERE ARE NO MARKINGS

INCLUDES: ALL BOTTOM LID ITEMS EXCEPT BAG

BASE
(2) BASES FOR NON RETURN FLAP
(2) NON RETURN FLAPS
(2) SPRINGS
(2) FILTER BAG SUPPORTS
(2) BOTTOM LID BRACKETS

SOME, BUT NOT ALL OF THE INDIVIDUAL PARTS ARE ALSO AVAILABLE.
