Maytronics Bottom Lid Assy | 9995550

Description

MAYTRONICS | BOTTOM LID ASSY | 9995550

OPTIMUS 3295-180
MAYTRONICS 9995550

THIS IS THE COMPLETE BOTTOM LID ASSEMBLY USED ON MANY DOLPHIN CLEANERS
THIS FITS ON THE BOTTOM OF THE CLEANER AND IS WHERE THE BAG ATTACHES

MATERIAL: BASICALLY WHITE PLASTIC WITH A FEW YELLOW PLASTIC ITEMS
ALONG WITH THE METAL BAG SUPPORTS, SPRINGS, AND SCREWS

SHAPE: RECTANGULAR BASE WITH 2 METAL BAG SUPPORTS
THE METAL BAG SUPPORTS ARE HELD INTO THE BASE WITH A BLACK PLASTIC
6-SIDED LOCK THAT FITS AROUND THE BOTTOM OF EACH LEG

LENGTH: 12-5/8″

WIDTH: 8-1/4

HEIGHT: 9-1/2″ (FROM BASE TO TOP OF BAG SUPPORT)

MARKINGS:
THERE ARE NO MARKINGS

INCLUDES: ALL BOTTOM LID ITEMS EXCEPT BAG

BASE
(2) BASES FOR NON RETURN FLAP
(2) NON RETURN FLAPS
(2) SPRINGS
(2) FILTER BAG SUPPORTS
(2) BOTTOM LID BRACKETS
(4) FILTER SUPPORT LOCKS

SOME, BUT NOT ALL OF THE INDIVIDUAL PARTS ARE ALSO AVAILABLE.

SPECIAL NOTE – THERE IS ANOTHER BOTTOM LID ASSEMBLY USED IN SOME CLEANERS
THE BASE ON THE OTHER IS 12-1/2″ x 9-1/4″ WIDE
AND THE TOTAL HEIGHT IS ABOUT 5-3/8″ ON THE OTHER

THE PART NUMBER ON THAT ONE IS 3295-071
